Frame
Trail, SmartForm C3 Alloy, 142x12mm, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, KickFlip hidden 18mm 2-bolt kickstand mount, BSA-73, 27.5" wheels (XS, S) / 29" wheels (M, L, XL)
-
Fork
SR Suntour XCM Boost, coil, 100mm travel, 46mm offset (29"), 80mm travel, 42mm offset (27.5")
-
Headset
Semi-Integrated, 1-1/8"
-
Rear Derailleur
Shimano CUES U4000
-
Shifters
Shimano CUES U4000, 9-speed
-
Chain
KMC X9, 9-speed
-
Crank
Prowheel, Charm 30T
-
Rear Cogs
Shimano CUES, 11-46, 9-speed
-
Bottom Bracket
ProWheel, square taper
-
Brakes
Tektro M275 hydraulic disc, 160/160mm rotors
-
Brake Levers
Tektro hydraulic disc
-
Front Hub
Formula DC-51, 15x100mm
-
Rear Hub
Formula DC-1422, 12x142mm
-
Rims
WTB SX19, 32h
-
Spokes
Stainless Steel, 14g
-
Tire Size
2.25
-
Wheel Size
27.5/29
-
Tires
WTB Ranger, 27.5x2.25" (XS, S) / 29x2.25" (M, L, XL)
-
Front Tire
WTB Ranger, 27.5x2.25" (XS, S) / 29x2.25" (M, L, XL)
-
Rear Tire
WTB Ranger, 27.5x2.25" (XS, S) / 29x2.25" (M, L, XL)
-
Handlebar
Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
-
Stem
Cannondale 4, 6061 Alloy, 31.8, 6°
-
Grips
Cannondale
-
Saddle
Cannondale Trail
-
Seatpost
Cannondale 4, 6061 Alloy, 31.6
